LKV993KVM-V3.0
4K60Hz HDMI KVM Optical EXTENDER
· Features
1. Supports resolution up to 4K@60Hz, backwards compatible.
2. Built on ipcolor PIXEL technology to deliver zero compression AV signals across long distances with ultra-low latency.
3. Supports EDID Pass-back.
4. Compatible with HDMI2.0, also compatible with HDCP1.4/HDCP2.2.
5. Extend 4K@60Hz HDMI signal up to 40 kilometers over LC single-mode fiber optic cable.
6. Supports one-to-one, one-to-many connection and 10G switch cascading.
7. Supports cascading of multiple receivers.
8. Supports bi-directional IR passthrough(20~60KHz).
9. Supports RS-232 passthrough and command control.
10. Supports HDMI ARC and HDMI CEC.
11. Supports KVM function.
12. With audio embedding and extraction, and the Receiver supports S/PDIF audio output.
13. The Transmitter supports HDMI loop out.
14. Firmware upgrading via Micro USB port.
15. Lightning protection, surge protection, ESD protection.
16. Working 24/7.
17. Supports dolby vision
More
LKV752KVM
1080P@60Hz 40KM HDMI™ over IP Optical KVM Extender
This product is a Full HD HDMI™ KVM optical extender kit consisting of
a transmitter and a receiver, using ipcolor STREAM technology for highdefinition,
low-latency transmission. The 1080P@60Hz HDMI™ signal can
be extended up to 40km by LC single-mode fiber cable, supporting
one-to-one connection, one-to-many connection via gigabit switch, or
switch cascading. It also supports HDMI™ loop out, KVM, and RS-232
passthrough, and can be widely used in meetings, home entertainment,
educational presentations, and other fields.
More
LKV982KVM
4K@60Hz 40KM HDMI™ over IP KVM Optical Extender
This product is a 4K@60Hz HDMI™ KVM optical extender kit consisting of
a transmitter and a receiver, using ipcolor STREAM technology for highdefinition,
low-latency transmission. The 4k@60Hz HDMI™ signal can be
extended up to 40km by LC single-mode fiber cable, supporting
one-to-one connection, one-to-many connection via gigabit switch, or
switch cascading. It also supports HDMI™ loop out, KVM, and RS-232
passthrough, and can be widely used in meetings, home entertainment,
educational presentations, and other fields.
More
LKV762KVM
1080P@60Hz HDR Uncompressed HDMI™ Over IP KVM Optical Extender
This is an HDMI™ KVM over IP optical fiber extender kit, including a
transmitter and a receiver. With this device, HDMI™ signals can be
transmitted at low latency and visually lossless over 40km with singlemode
fiber optic cable at 1080p@60Hz resolution. This HDMI™ over IP
optical KVM extender kit supports HDMI™ loop out, KVM, RS-232
passthrough, and audio extraction through S/PDIF output on the receiver.
It supports point-to-point connection or one-to-many connection
through gigabit switch, and cascading of switches is also supported. This
extender kit is a reliable video transmission and distribution solution
which can be widely used in security monitoring, rail transit, broadcasting,
smart cities, home theatre and other fields.
